DSL-330 Digital Sound Level Meter

(No reviews yet) Write a Review
SKU:
DSL-330
MPN:
DSL-330
Weight:
500.00 Grams
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
  • DSL-330 Digital Sound Level Meter, DSL-330, Digital Sound Level Meter, tecpel
  • DSL-330 Digital Sound Level Meter, DSL-330, Digital Sound Level Meter, tecpel
  • DSL-330 Digital Sound Level Meter, DSL-330, Digital Sound Level Meter, tecpel
  • DSL-330 Digital Sound Level Meter, DSL-330, Digital Sound Level Meter, tecpel
  • DSL-330 Digital Sound Level Meter, DSL-330, Digital Sound Level Meter, tecpel
$237.00

Description

A sound levelmeter is a measuring instrument used to assess noise or sound levels by measuring sound pressure. Often referred to as a sound pressure level (SPL) meter, decibel (dB) meter, noise meter or noise dosimeter, a sound level meter uses a microphone to capture sound.

DSL-330 from Tecpel is a handheld sound level meter used to take acoustic measurements.

DSL-330 from Tecpel comes with the following properties:

  • Measuring range: 30 ~ 130 dB.
  • High, Med, Low 3 ranges.
  • Frequency weighting: A, C.
  • 4-Digit display with updated cycle 0.5s.
  • 0.1dB resolution.
  • Max /Min hold function.
  • The standard fast and slow time weightings.
  • AC/DC signal output.
  • Overload condition indication.
  • Auxiliary output jack.
  • IEC 651 type II, ANSI S1.4 Type2.
  • Back screw hole tripod connection.
  • Calibration Potentiometer easy to adjust.

Product Specifications

Features

Range/Description

  • Standard Applied

IEC651 Type 2, ANSI S1.4 Type 2.

  • Frequency Range

31.5Hz ~ 8KHz.

  • Measuring Level Range

30 ~ 130dB.

  • Frequency Weighting

A/C.

  • Microphone

1/2 inch electric condenser microphone.

  • Display

LCD Back Light Function.

  • Digital Display


4 digits, Resolution: 0.1dB; Display Update: 0.5 sec.

  • Analog Display

50 segment Bar graph, Resolution, Resolution: 1dB, Display update: 50mS

  • Time weighting

Fast (125ms); Slow (1 sec).

  • Level Range

Lo: 30~80dB; Med: 50~100dB, Hi: 80~ 130dB; Auto Range: 30~ 130 dB.

  • Accuracy

±1.5dB (under reference condition at 94dB 1KHz).

  • Measuring Level Range

30 ~ 130dB.

  • Dynamic range

100dB.

  • Over and Under range Indication Function

"OVER" is displayed, while input is more than upper limit of range. ;
" UNDER" is displayed, while input is less than lower limit of range.

  • MAX/MIN Hold

Hold Reading the Maximum and Minimum Value.

  • AC Output

1V RMS at FS (Full Scale).

  • Output impedance

Approx. 100 Ω.

  • DC Output

10mV/dB, Output impedance approx. 1K Ω

  • Auto Power Off

30 minutes if no operation.

  • Power Requirement

One piece 9V battery NEDA 1604.

  • Power Life

About 50 Hours (Alkaline battery).

  • AC Adapter (option)

Voltage 9VDC (8~ 15 V DC Max); Supply current : > 30mADC.

  • Operation Temperature

0 to 40 ºC (32 to 104 ºF).

  • Operation Humidity

10 to 90% RH.

  • Storage Humidity

10 to 75% RH.

  • Weight

10 oz (285g).

  • Accessories:

9V battery, Carrying case, calibration screwdriver, 3.5Ø plug, windscreen and owner’s manual.

Brand Information

Tecpel Co. Ltd. has over 20 years of experience in the Test and Measurement market. They have set up over 50 country distributors worldwide. Some of their products have been branded by famous leaders in the market. About 60% of their customers are repeat customers. Tecpel imports products from Japan and carries out quality checks. Their products are exported to Europe mainly. If customers find a fault with the product, they will replace it with a new product within 2-3 days.

They are regarded as one of the leading Taiwanese manufactures of high quality test and measurements. Their product lines include power supplies, oscilloscopes, electronics & electrical meters and testers. Tecpel’s quality products have been accepted by some well-known international customers. The confidence they have in their products is reflected in their one-year warranty and by their flat-rate service policy through 3-5 years.
