DMM-129 Digital Multimeter

(No reviews yet) Write a Review
SKU:
DMM-129
MPN:
DMM-129
Weight:
500.00 Grams
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$170.00

Description

A multimeter or a multi-tester, also known as a VOM (volt, ohm, milli-ammeter), is an electronic measuring instrument that combines several measurement functions in one unit. A typical multimeter can measure voltage, current, and resistance. Analog multimeters use a micro-ammeter with a moving pointer to display readings.

DMM-129 from Tecpel is a compact, rugged digital multimeter which includes AC True RMS measurement. This multimeter is ideal for use by electronic engineers, electricians, and home applications. It features Overload protection and Sleep mode

DMM-129 from Tecpel comes with the following features:

  • 3 3/4 Digits, 3,999 counts.
  • AC True RMS.
  • Auto / Manual range.
  • 42 Segment analog bar graph.
  • Data Hold / Max-Min memory.
  • Relative mode.
  • Capacitance measurement.
  • Overload protection.
  • Frequency measurement.
  • Audible continuity check.
  • Diode test.
  • 30-minute Auto power-off.
  • 20Amp range measurement.
  • Double fuse protection (0.4A, 20A).



Product Specifications

Features

Range/Description

  • DC Voltage Ranges

400mV, 4V, 40V, 400V, 1000V, ± (0.3%+3dgt).

  • AC Voltage Ranges

400mV, 4V, 40V, 400V, 750V ± (2.0%+7dgts).

  • DC current ranges

40mA, 400mA, 20A, ± (1%+5dgt).

  • AC current ranges

40mA, 400mA, 20A, ± (1.5%+5dgt).

  • Resistance Ranges

400, 4k, 40k, 400k, 4MΩ, 40MΩ ± (1.0%+2dgts).

  • Capacitance range

4nF, 40nF, 400nF, 4uF, 40uF± (1%+2dgt).

  • Temperature

-20~750, -4~1400, ± (3.0%rdg+2), ±(3.0%rdg+4).

  • Frequency Range

100, 1K, 100K, 600KHz ± (0.5%+2dgt)

  • Overload protection

450V DC or AC RMS for DC/AC voltage, R, diode, continuity.

  • Power Requirement

Dual 1.5V no.4 battery.

  • Dimensions

1.2""x3.2""x6.9"" (32x82x176mm).

  • Weight

13.9 oz (395g).



Brand Information

Tecpel Co. Ltd. has over 20 years of experience in the Test and Measurement market. They have set up over 50 country distributors worldwide. Some of their products have been branded by famous leaders in the market. About 60% of their customers are repeat customers. Tecpel imports products from Japan and carries out quality checks. Their products are exported to Europe mainly. If customers find a fault with the product, they will replace it with a new product within 2-3 days.

They are regarded as one of the leading Taiwanese manufactures of high quality test and measurements. Their product lines include power supplies, oscilloscopes, electronics & electrical meters and testers. Tecpel’s quality products have been accepted by some well-known international customers. The confidence they have in their products is reflected in their one-year warranty and by their flat-rate service policy through 3-5 years.

View AllClose

Warranty Information

One-Year Warranty
